city logistics vehicle
wonderful details
multi-angle shot
fabulous from every angle
| project | car | economic electricity consumption (degree / 100km full load) | |
| l*w*h（mm） | 2990*1090*1650 | maximum speed (km/h) | 32 |
| case l*w*h（mm） | 1390*1050*1040 | climbing ability (% full load) | 15 |
| wheelbase（mm） | 2100 | range | 60-80km |
| minimum turning radius（mm） | 4300 | auxiliary function configuration | |
| track (back)(mm) | 1000 | wiper system | ● |
| number of seats (a) | 1 | folding adjustable rear exterior mirror | ● |
| curing quality (kg) | 360(without battery) | high-elastic leather seat | ● |
| motor rated power（kw/rpm） | 1.5kw | lcd electronic digital instrument | ● |
| motor rated voltage（v） | 60v | reversing beep warning | ● |
| battery type | colloid-free maintenance battery | reversing image (compatible with usb mobile phone charging device) | ● |
| motor type | permanent magnet synchronization | stereo speakers (a) | ● |
| battery specification | 45ah-60ah optional | luxury headlights | ● |
| number of batteries (block) | 5 blocks | combined led tail light | ● |
| charger type | external charger | reversing light | ● |
| charging voltage（v） | 220v | license plate light | ● |
| shift type | controller automatic speed regulation | natural wind | ● |
| drive mode | rear drive | warm air | ● |
| suspension system | front fork suspension / rear wheel integral damping damping suspension | mobile phone holder | ○ |
| car body structure | carrier frame structure | foldable tablet | ● |
| braking system | front drum rear disc brake | fire extinguisher | ○ |
| parking brake type | foot brake | anti-theft device | ○ |
| tire specifications | 4.00-10 | the color of car | sky white, blue butterfly gray |
| performance | |||
| note: “—” is no such configuration; “●” is a standard configuration mount; “○” is an optional device | |||
